OT BOX

Prosthesis made entirely from resin with overdenture attachments A cast reinforcement will prevent the prostheses from breaking.
With the OT Box bar, the reinforcement is created directly on the master model without duplicating it.
The cast reinforcement, complete with the container for the retention caps. Any type of alloy may be used for the casting. The optimal result of the retention capsize in the metal housing (or cast or prefabricated) that are constructed with a tolerance, calculated to permit the perimeter of the opening of the cap .
It is a procedure that can be done in one quick simple step. The case, even if it is not, the elasticity and the width of the material permit, even if less, an elastic movement of the perimeter during insertion of the sphere.
Oversized castable housing; For positioning caps chairside

product info
study
laboratory procedure
product specifications
Videos and Documents

Product Information

Scatola OTBOX SPECIAL Normal 058BSNOT Box Special - Normal + Connectors

Ref. 058BSN
Kit Contains:
• 2 OT Box Special Bars
• 4 Plastic Positioners
• 4 Connectors


Scatola OTBOX SPECIAL Micro 058BSMOT Box Special - Micro + Connectors

Ref. 058BSM
Kit Contains:
• 2 OT Box Special Bars
• 4 Plastic Positioners
• 4 Connectors




Scatola OTBOX CLASSIC NORMO 153BCN

OT Box Classic - Normal + Connectors

Ref. 153BCN
Kit Contains:
• 2 Upper Bars
• 2 Lower Bars
• 4 Plastic Positioners
• 4 Connectors


Scatola OTBOX CLASSIC MICRO 153BCMOT Box Classic - Micro + Connectors

Ref. 153BCM
Kit Contains:
• 2 Upper Bars
• 2 Lower Bars
• 4 Plastic Positioners
• 4 Connectors

Studio

116

Titanium posts fixed on the root

117Fix the retnetive caps before taking the impression.

120

It is reccommended to use a very hard impresson material to grant the right position of the cap. The lab will insert the analog for the sphere.

Plaster model with sphere analog.

Plaster model with covers and sphere.

115

Cast reinforcement wax-up on the master model without duplication.

Laboratory

Cast OT Box Large. The tolerance between caps and housing it is calculated to compensate possible mistakes during the different working phases of the attachment. The dentist will fix the cap directly into the mouth of the patient afterwards.

OT Box Classic. Glue together the two OT Box bars.

Use this piece as the housing.

OT Box Special.Cut the mono bar and use only the necessary part as a housing.

Model a layer of wax on the ridge and make three holes in contact with the plaster. Insert the positioning rings on the spheres.

Position the OT Box Classic or Special housings on rings. Complete the reinforcement using connectors and join the various pieces with self-polymerising resin.

Modelling completed and cast pivot applied.

Finished cast with retentive caps inserted.

Finished prosthesis with cast reinforcement incorporated.

when the mask is in position, insert pins in single teeth in order to make a reinforcement.
