OT Cap

The extracoronal OT Cap castable attachments are used in combination prostheses, frames, connecting bars on natural teeth, roots and implants.

On prosthetic projects with a rigid structure with appropriate milling and counterattacks, they work as retentive stabilizer buttons.

In resilient prosthetics without milling, they work with shock-like yielding due to the flat ball head and the elastic retentive caps.

It is also possible to manage the seal by applying the appropriate colored cap and seal. At the discretion, in addition to the nylon-only caps, the TITAN CAP caps can also be applied. OT CAP TECNO attachments must be considered precision attachments.

The titanium sphere and the titanium ring incorporated in the nylon cap are mechanically constructed with calculated tolerances that ensure good accuracy.

In addition, the etching during the processing does not run any risks due to sandblasting, polishing and various passages in the kiln firing furnace, since the ball-attachment is fixed in parallel on the die only when the work is finished.

product info
studio
laboratory procedure
product specifications
Videos and Documents

Info Product

OT Cap distal extention


Sfera-FlexRef. 038STF
Titanium Flex Single Sphere - Normal Size + TiN Coating
for laser soldering or bonding

Kit Contains:


• 2 Single Titanium Flex Spheres
• 2 Pink Caps - Soft Retention)
• 1 Sphere Holder
• 2 Castable Sliding Bases

Sfera-Fissa-con-guida

Ref. 038STN
Titanium Flex Single Sphere - Normal Size + TiN Coating
for laser soldering or bonding
Kit Contains:
• 2 Single Titanium Spheres
• 2 Pink Caps - Soft Retention
• 2 Pink Caps - Soft Retention
• 2 Castable Sliding Bases

Sfera-Fissa-micro-con-guida

Ref. 038STMTitanium Flex Single Sphere - Normal Size + TiN Coating
for laser soldering or bonding
Kit Contains:
• 2 Single Titanium Spheres
• 2 Pink Caps - Soft Retention
• 1 Sphere Holder
•2 CALCINABLE GUIDE BASES

Scatola OT-CAP Calcinabile NORMO Singolo 2016 092CANRef. 092CAN
OT - Cap Standard Size Kit Contains:
• 4 Single Spheres
• 4 Pink Caps - Soft Retention
• 4 Stainless Steel  Housings (2 for Resin, 2 for Soldering)
• 4 Plastic Positioners


Scatola OT-CAP Calcinabile MICRO Singolo 2016 092CAMRef. 092CAM
OT Cap - Micro SizeKit Contains:
• 4 Single Spheres
• 4 Pink Caps - Soft Retention
• 4 Stainless Steel  Housings (2 for Resin, 2 for Soldering)
• 4 Plastic Positioners


Scatola OT-CAP Calcinabile NORMO Economico 196BCNRef. 196BCN
Economic OT Cap - Standard Size
Kit Contains:
• 1 Castable Pre-Sectioned Bar
• 1 Castable Pre-Sectioned Beveled Bar
• 4 White Retentive Caps (Standard Retention)


Scatola OT-CAP Calcinabile MICRO Economico 197BCMRef. 197BCM
Economic OT Cap - Micro Size
Kit Contains:
• 1 Castable Pre-Sectioned Bar
• 1 Castable Pre-Sectioned Beveled Bar
• 4 White Retentive Caps (Standard Retention)




Scatola OTBOX MONO NORMO 099BSNRef. 099BSN
OT Cap & Mono OT Box For Frame - Standard Size
Kit Contains:

• 2 Castable Pre-Sectioned Bars (1 Straight, 1 Beveled)
• 4 White Retentive Caps (Standard Retention)
• 4 Castable Mono OT Box
• 4 Plastic Positioners


Scatola OTBOX MONO NMICRO 099BSMRef. 099BSM
OT Cap & Mono OT Box For Frame - Micro Size
Kit Contains:
• 2 Castable Pre-Sectioned Bars (1 Straight, 1 Beveled)
• 4 White Retentive Caps (Standard Retention)
• 4 Castable Mono OT Box
• 4 Plastic Positioners


Scatola OT CAP TECNO NORMO 093CTNScatola OT CAP TECNO MICRO 093CTM

Ref. 093TCN (NORMal)
Ref. 093TCM (MICRO)
OT CAP TECNO
Kit Contains:
• 2 PRE-ANGULATED CASTABLE EXTENSIONS
• 2 TITANIUM SINGLE THREADED SPHERES
•  2 TITANIUM BOND-IN THREADED SLEEVES
• 2 TRANSPARENT CAPS NORMAL/MICRO
• 2 PINK CAPS NORMAL/MICRO
• 2 YELLOW CAPS NORMAL/MICRO

Spare parts - Normal - 2.5mm


OT Cap Normo Calcinabile 055SCNRef. 055SCN
• 4 Castable Single Spheres - Normal


OT CAP Barra Calcinabile Normo verde 151BANRef. 151BAN
• 2 Pre-Sectioned Beveled Bars - Normal


OT CAP Barra Calcinabile dritta Normo verdeRef. 150BPN
• 2 Pre-Sectioned Beveled Bars - Normal


otcap NORMO argentoRef. 048CAN
• 6 Silver Caps - Extra - Soft Retention Elastic and Gummy - Normal 350 gr.


otcap NORMO oroRef.048CON
• 6 Gold Caps - Soft Retention - Extra resilient - Normal 500 gr.


otcap NORMO verdeRef. 049PCN
• Green Caps - Very Elastic Retention - Normal 350 gr.


otcap NORMO giallaRef. 060CRNAY
• 6 Yellow Caps - Extra Soft Retention - Normal 500 gr.


otcap NORMO rosaRef. 040CRNSN
6 Pink Caps - Soft Retention - Normal 900 gr.


otcap NORMO trasparenteRef. 040CRN
• 6 Clear Caps - Standard Retention - Normal 1300 gr.


otcap NORMO titanRef. 040TCN
• 2 Titan Caps - Normal 1500 gr.


otcap NORMO neraRef. 043CLN
• 6 Black Caps for laboratory use - Normal


otcap NORMO acquaRef. 040CRNDR8
• 6 Water Green Caps - Hard retention - Normal 1300 gr.
Undersized internal diameter for worn 2.5 mm sphere or for 2.2 mm sphere


otcap NORMO rosaRef. 040CRNSNDR8
• 6 Pink Caps - Standard Retention - Normal 900 gr.
Undersized internal diameter for worn 2.5 mm sphere or for 2.2 mm sphere


otcap NORMO arancio

Ref. 049PCNDR8
• 6 Orange Caps - Very Elastic Retention - Normal 350 gr

Undersized internal diameter for worn 2.5 mm sphere or for 2.2 mm sphere


otcap calcinabile NORMO

Ref. 042AMN
• 2 Mono OT Box - Normo
Castable Housing for Caps



Contenitore NORMO inoxRef. 041CAN
• 2 Stainless Steel Housings - Normo


Contenitore NORMO titanioRef. 041CTN
• 2 Titanium Housings - Normo




OT Cap posizionatore NORMORef. 101PPN
• 2 Plastic Positioners - Normo


Spare parts - Micro - 1.8mm


OT Cap Micro Calcinabile 055SCMRef. 055SCM
• 4 Castable Single Spheres - Micro


OT CAP Barra Calcinabile Micro Rossa 151BAMRef. 151BAM
• 2 Pre-Sectioned Beveled Bars - Micro


OT CAP Barra Calcinabile dritta Micro RossaRef. 150BPM
• 2 Pre-Sectioned Beveled Bars - Micro


otcap MICRO argentoRef. 048CAM
• 6 Silver Caps - Extra Soft Retention Elastic and Gummy - Micro 200 gr.


otcap MICRO oroRef. 048COM
• 6 Gold Caps - Soft Retention Extra resilient - Micro 450 gr.


otcap MICRO verdeRef. 049PCM
• 6 Green Caps - Very Elastic Retention - Micro 200 gr.


otcap MICRO giallaRef. 060CRMAY
• 6 Yellow Caps - Extra Soft Retention - Micro 450 gr.


otcap MICRO rosaRef. 040CRMSN
• 6 Pink Caps - Soft Retention - Micro 800 gr.


otcap MICRO trasparenteRef. 040CRM
• 6 Clear Caps - Standard Retention - Micro 1100 gr.


otcap MICRO titanRef. 040TCM
• 2 Titan Caps - Standard Size - Micro 1300 gr.


otcap MICRO neraRef. 043CLM
• 6 Black Caps for Laboratory Use - Micro




otcap MICRO acqua

Ref. 040CRMDR8
• 6 Water Green Caps - Hard retention - Micro 1100 gr.
Undersized internal diameter for worn 2.5 mm sphere or for 1.6 mm sphere


otcap MICRO arancio

Ref. 049PCMDR8
• 6 Orange Caps - Very Elastic Retention - Micro 200 gr

Undersized internal diameter for worn 2.5 mm sphere or for 1,6 mm sphere


otcap calcinabile MICRO

Ref. 042AMM
• 2 Mono OT Box - Normo

Castable Housing for Caps


Contenitore NORMO inoxRef. 041CAM
• 2 Stainless Steel Housings - Micro


Contenitore MICRO titanioRef. 041CTM
• 2 Titanium Housings - Micro




OT Cap posizionatore MICRO

Ref. 101PPM
• 2 Plastic Positioners - Micro


Accessories - Normo and Micro size


analogo ot-Cap NormoRef. 044PPN
• 2 Transfer Pivot - Normo


Ref. 100SAN
• 10 - Aluminum Spacers - Normo - for OT Box Bars




analogo ot-Cap MicroRef. 044PPM
• 2 Transfer Pivots - Micro


Ref. 100SAM
• 10 Aluminum Spacers - Micro - for OT Box Bars


connectorRef. 155CC
• 6 Connectors


Sfera-Cava-normo

Ref. 187CRS
• 2 Concave Spheres - Available: 1.8 mm, 2.2 mm, 2.5 mm




Sfera-Solida-Ricostruttiva



Ref. 189SRS
• 2 Solid Spheres - Available: ø 1,8mm


dischetto-protettivoRef. 100PD
• 10 Protective Disks


Sfera-Fissa-Guida calcinabile Ref. 038GCS
• 2 Castable Sliding Bases


analogo ot-Cap MicroRef. 044PP22
• 2 Micro Transfer Pivots - 2.2 mm


Tools- normo and micro size


Inseritore-Estrattore-485IC

Ref. 485IC
Insertion Tool for Caps normo/micro


Chiave parallel Ref 744AC01Ref. 74AC01
Parallelometer Key Normo


Chiave parallel Ref 744AC01Ref. 74AC02
Parallelometer Key Micro


Chiave Parallelometro OT TECNORef.74AC03
Tecno Parallelometer Key Normo and Micro


Estrattore-491EC

Ref. 491EC
Multi-purpose coping extractor (with rod holder hole)


Ref. 080RCN
Reamer Tool for OT Cap Normo


Ref. 080RCM
Reamer Tool for OT Cap Micro


Ref. 082ATN
Attrezzo di controllo tenuta Normo


Ref. 083ATM
Reamer Tool for OT Cap Normo


Ref. 083ATM
Reamer Tool for OT Cap Micro

Studio

Laboratory

Calcinable bars

Remove the bar portion from use

Mount in parallel using the appropriate key (golden)


Cut the bar

Mount in parallel using the appropriate key (golden)

Finish and polish the support: leave the stump rough ball holder
